Description
Basic Information |
||
| Supported CPU | Support for Intel 4th Gen Core i7 / i5 / i3, Pentium, Celeron, and Xeon E3-1200 v3 series CPU Socket: LGA 1150 |
|
| Chipset | Intel B85 Express Chipset | |
| Form Factor | Micro-ATX (180 mm x 216 mm) | |
| Audio | 3x 3.5mm Audio Jacks (Line-In, Line-Out, Mic-In) | |
Expansion Slots |
||
| PCI | 1x PCIe 2.0 x16 Slot, 1x PCIe 2.0 x1 Slot | |
Memory |
||
| Type | DDR3 | |
| Slots | 2x DDR3 DIMM Slots (240-pin) | |
| Supported Memory | 1600 / 1333 / 1066 MHz | |
| Maximum Memory | Up to 16 GB (Supports up to 8 GB per single slot) | |
Connector & Ports |
||
| HDMI | 1x HDMI | |
| VGA (s) | 1x VGA (D-Sub) | |
| USB (s) | 2x USB 3.0 Ports, 4x USB 2.0 Ports | |
| LAN Port (s) | 1x RJ45 Gigabit LAN Port (Realtek Gigabit Controller) | |
| Wireless Communication module | 1x M.2 Wi-Fi / WLAN Slot | |
| Supported Storage | 1x M.2 Slot (Supports NVMe PCIe 2.0 x4 & SATA 3.0 NGFF modes via hardware jumper selection) | |
| Audio | 3x 3.5mm Audio Jacks (Line-In, Line-Out, Mic-In) | |
| Internal I/O Ports | 2x FUSB 2.0 Headers (Supports 4 additional USB 2.0 front ports) 1x 4-Pin CPU Fan Connector, 1x 3-Pin System (SYS) Fan Connector 1x 14-Pin TPM 2.0 Header, 1x 2×5-Pin Diagnostic Card Header, 1x JCMOS Header 1x FPANEL Front Panel Header, 1x Front Panel Audio Header 24-Pin ATX Main Power + 4-Pin 12V CPU Power Receptacle |
|
Warranty Information |
||
| Manufacturing Warranty | 1 Year | |
