Description
| Processor | |
| Processor |
1GHz CPU
|
| Networking & Connectivity | |
| Network Standard |
Wi-Fi 6
IEEE 802.11ax/ac/n/a 5 GHz IEEE 802.11b/g/n 2.4 GHz |
| Bandwidth |
AX1500
5 GHz: 1201Mbps (802.11ax) 2.4 GHz: 300Mbps (802.11n) |
| Protocols |
IPv4, IPv6
|
| Frequency Range |
3 Bedroom Houses
4x Fixed High-Performance Antennas Multiple antennas form a signal-boosting array to cover more directions and large areas Beamforming Concentrates wireless signal strength towards clients to expand WiFi range High-Power FEM Improves transmission power to strengthen signal coverage |
| Guest Network Support |
1*5GHz Guest Network /1*2.4GHz Guest Network
|
| Encryption |
WPA-PSK, WPA2-PSK, WPA/WPA2-PSK,WPA3
|
| Ports | |
| WAN |
DHCP, Static IP, PPPoE, L2TP, PPTP
|
| Interface |
1* Gigabit WAN Port+3*Gigabit LAN Ports
|
| Special Features | |
| Certifications |
FCC, CE, RoHS, EAC, UkrSEPRO
|
| Speacial Features |
Port mapping: Virtual Server, DMZ
IPTV: Bridge, Tag VLAN Dynamic DNS: DynDns, no-ip WiFi Transmission Power: 2.4H: 22DB 5G: 19DB FOTA, TR069, Remote Access, Backup & Restore |
| Others | |
| Button |
WPS/MESH、RESET
|
| Other Features |
WiFi Capacity: Dual-Band
Allocate devices to different bands for optimal performance OFDMA Simultaneously communicates with multiple Wi-Fi 6/5/4 clients Airtime Fairness Improves network efficiency by limiting excessive occupation 4 Streams Connect your devices to more bandwidth Working Modes Router Mode: Repeater Mode |
| Physical Specification | |
| Environment |
Operating Temperature: 0℃~40℃ ( 32℉ ~104℉ )
Storage Temperature: -40℃~70℃ (-40℉ ~158℉ ) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
| Dimension |
226*144*190.5mm
|
| Technical Info | |
| Flash |
128MB/16MB
|
| System Requirements |
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Cable Subscription with an internet service provider (for internet access) |
